This is a special-order item that requires additional lead time. Contact us before ordering if you need a more exact ETA.
Skyus™ 160 Gateway for high-speed connectivity in fixed and mobile environments.
Plug and play: With the Skyus 160 you can easily connect to a 4G LTE network. The two SMA external cellular antennas extend your coverage to enhance your wireless connection.
Remote networking: Skyus 160 provides fast connection speeds for remote branches, pop-up stores, kiosks, self-serve retail, and work and learn from home environments.
Flexible deployment configurations: Access data via Ethernet, USB, or Wi-Fi and power Skyus 160 using USB, PoE (power over ethernet), or DC.
Backup power like no other: The 4400mAh battery keeps your business connected for up to 12 hours1 and charges quickly thanks to Quick Charge™ 2.0 technology.
Secure and Encrypted: Skyus 160 safeguards your data with advanced encryption, hacker prevention, and password protection features.
SPECIFICATIONS
| Network connectivity2 |
- 4G LTE Cat 7 B2, B4, B5, B7, B12, B13, B14, B25, B26, B41, B42, B43, B48, B66, B71 (Supports 2 carrier aggregation downlink)
- 3G (HSPA+, UMTS) B2, B4, B5
|
|
Wi-Fi
|
- Wi-Fi 5 (802.11 a/b/g/n/ac)
- Supports up to 15 clients
|
| Chipset |
|
| Data Rates |
- 300 Mbps downlink, 150 Mbps uplink3
|
| GNSS |
- aGNSS (GPS, GLONASS, Galileo)
- NMEA, SUPL 2.0 support
- Local UDP
- Remote streaming
|
| Data Interfaces |
- USB Micro-B (host or device)
- RJ45 Ethernet (PoE in)
- Wi-Fi
- Bluetooth
|
| Bluetooth |
|
| Power |
- 5 ± 0.25 VDC @ 1A (powered USB 2.0 connection required) via USB nicro-B connector
- 9-32 VDC via 4-pin connector
- PoE in from PoE host
|
| Backup Battery |
- 4400 mAh Li-ion rechargeable pack
- 12 hours of backup power1
|
| Charging |
- 14.4W Qualcomm® Quick Charge™ 2.0 charger
- USB type A to C cable
|
|
Antennas
|
- Two SMAs for external Cellular antennas
- One SMA for external GNSS antenna
- Internal Wi-Fi/BT antennas
|
| Mounting |
- Integrated mounting tabs for #4 or #6 screws
|
| Dimensions & Weight |
- 118 x 98 x 33 mm (4.65 x 3.85 x 1.31 in)
- 240 g (8.5 oz)
|
| User Interface |
- Skyus web UI (https://my.skyus/ or 192.168.1.1)
|
| Operating Temperature |
- Normal operation: -20– 50 °C (-4 – 122 °F)
- Storage: -20 – 60 °C (-4 – 140 °F)
|
| Networking |
- Port forwarding/filtering
- VPN passthrough
- IP passthrough
- MAC filtering
- DHCP
|
| Systems Supported |
- Windows® 7 or newer
- Linux Ubuntu 14.04 or newer
- Linux Kernel 2.6.32 or newer
|
| Compliance |
- FCC, PTCRB, ISED, CA BCS, CA Prop 65 (USA)
|
NOTES
1 Theoretical values, battery life and charge time may vary depending on the number of connected devices and activity.
2 Data plan required. Coverage subject to network availability.
3 Theoretical values, speeds achieved by connected devices vary based on network coverage, Wi-Fi connection and device capability.
