Pepwave AP One AX Lite (Dual Band 2x2 WiFi 6)

27 Customer Reviews 3 Questions 30 Support Docs

In Stock

Item Number: 11019
Model: APO-AX-LITE

Quantity:

Have a large deployment?
Request a Quote

Price:

$299.00

Add POE Injector if Needed - details

View Available Service Items

General

Details

Customer Reviews

Q & A

Support

Photos & Videos

Pepwave AP One AX Lite (Dual Band 2x2 WiFi 6) Effortlessly integrate Peplink solutions with AP One AX Lite to provide unique network capabilities and network flexibility, making the whole experience more user friendly. AP One AX Lite comes equipped with InControl central management. Giving users the ability to control and monitor their network from any web browser. Manage network SSIDs, radio settings, and search event logs with ease to diagnose the entire network. Integrated Wi-Fi 6 is 45% faster than the average Wi-Fi 5, has 4 more device capacity and consumes less power for connected devices, and it supports 802.11k/v/r, providing users a seamless roaming experience between access points. Applications: Enterprise: AP One gives you the perfect combination of enterprise features and affordability. Relying on consumer level gear can mean dealing with frequent reboots and security holes. AP One provides the features you need with enterprise grade reliability. Branch Networking: Whether you have five locations or 500, AP One and InControl make it easy to deploy a seamless wireless network. With Zero-Touch configuration and real-time reporting you can manage a global network from anywhere you have Internet access. Hospitality: AP One makes setting up a login portal for your guests incredibly simple. With InControl you can have all of your APs configured and your portal secured in minutes. AP One also comes with GuestProtect, a set of features designed to keep your network and your guests computers secure. Education: Both students and staff need access to the Internet, though each group has different needs and, in turn, requires a different set of rules and restrictions. AP One's flexible group policy controls allow you to create separate networks to allow all parties to access the Internet with appropriate security policies in place. Home: AP One isn't just for serious business, it’s also the perfect fit for connecting cutting edge home entertainment systems and computers. Now you can have all the reliability and speed of a professional network at home. Whether you have a small home or a large property, AP One and InControl can keep your family and friends connected. Resources Comparing Peplink WiFi Access Points: Which AP is Right for Your Network? APO-AX-LITE APO-AX-LITE

Peplink

Router > Access Point

631060836850

$ $299.00 631060836850 https://5gstore.com/product/11019_pepwave_ap_one_ax_lite_dual_band_2x2_wifi_6.html

4.63 27

Effortlessly integrate Peplink solutions with AP One AX Lite to provide unique network capabilities and network flexibility, making the whole experience more user friendly.

AP One AX Lite comes equipped with InControl central management. Giving users the ability to control and monitor their network from any web browser. Manage network SSIDs, radio settings, and search event logs with ease to diagnose the entire network.

Integrated Wi-Fi 6 is 45% faster than the average Wi-Fi 5, has 4 more device capacity and consumes less power for connected devices, and it supports 802.11k/v/r, providing users a seamless roaming experience between access points.

5Gstore is a Peplink Certified Partner Applications:

Enterprise: AP One gives you the perfect combination of enterprise features and affordability. Relying on consumer level gear can mean dealing with frequent reboots and security holes. AP One provides the features you need with enterprise grade reliability.
Branch Networking: Whether you have five locations or 500, AP One and InControl make it easy to deploy a seamless wireless network. With Zero-Touch configuration and real-time reporting you can manage a global network from anywhere you have Internet access.
Hospitality: AP One makes setting up a login portal for your guests incredibly simple. With InControl you can have all of your APs configured and your portal secured in minutes. AP One also comes with GuestProtect, a set of features designed to keep your network and your guests computers secure.
Education: Both students and staff need access to the Internet, though each group has different needs and, in turn, requires a different set of rules and restrictions. AP One's flexible group policy controls allow you to create separate networks to allow all parties to access the Internet with appropriate security policies in place.
Home: AP One isn't just for serious business, it’s also the perfect fit for connecting cutting edge home entertainment systems and computers. Now you can have all the reliability and speed of a professional network at home. Whether you have a small home or a large property, AP One and InControl can keep your family and friends connected.

Resources

Comparing Peplink WiFi Access Points: Which AP is Right for Your Network?

Latest Blog Posts About This Product

Latest YouTube Videos About This Product

pepwave_apone_datasheet(5427).pdf

pepwave_ap_one_ax_lite_datasheet(11019).pdf

pepwave_ap_pro_AC_datasheet(4613).pdf

Peplink AP One AX installation guide (11019).pdf

Pepwave AP Pro 300M User Guide (4613).pdf

Pepwave AP Pro Duo User Manual (4616).pdf

Specifications:

Model
- APO-AX-LITE
Basic Specs
- Ethernet Port: 1x 1Gbps Ethernet port
- WiFi Standard
  - Simultaneous
  - 1 x 2.4GHz 802.11b/g/n/ax
  - 1 x 5GHz 802.11a/n/ac/ax
  - 2 x 2:2
- Data Rates:
  - 2.4GHz: up to 574 mbps
  - 5GHz: up to 1200 mbps
- WiFi Transmit Power:
  - 2.4GHz: up to 19dBm
  - 5GHz: up to 19dBm
- Recommended Concurrent Users Per Radio: 256
- Number of SSID Per Radio: 16
Hardware
- Antenna Type: Built-in omni antenna
  - 2 x 3dBi - 2.4GHz
  - 2 x 3dBi - 5GHz
- Enclosure: Plenum-rated
- Dimensions:5.9 x 5.9 x 1.3 inches
- Weight: 0.84 lbs
Operations:
- Power Input: 12V DC Jack (AC adapter not included), 802.3at PoE (Injector not included)
- Power Consumption: 14.5W (max.)
- Operating Temperature: 32° – 104°F / 0° – 40°C
- Humidity: 15% - 95% (non-condensing)
- Warranty: 1-Year Limited Warranty

Technical Specifications:

Network
- Bridge Mode
- Router (NAT) Mode
- Wireless Distribution System (WDS)
- Support for PPPoE, Static IP, DHCP
- Management VLAN (802.1p)
- Spanning Tree Protocol (802.1d)
Radio
- Multiple SSID
- Auto Channel Selection
- Transmit Power Adjustment
- Neighbor AP Detection
AP Security
- Open
- WPA-PSK/RADIUS
- WPA2-PSK/RADIUS
Client Managment
- Per SSID
  - VLAN with QoS (802.1p/802.1q)
  - Bandwidth Control
  - MAC Address Filtering
  - Layer 2 Client Isolation
  - Limit on Max. Number of Client
- Per Client
  - VLAN with RADIUS
  - VLAN with VLAN Pool
  - Bandwidth Control
  - Multicast Filter
  - IGMP Snooping/Multicast Enhancement
Complete VPN Solution
- PepVPN
  - Site-to-Site VPN
  - 256-bit AES Encryption
  - Pre-shared Key Authentication
  - Dynamic Routing
Captive Portal
- By InControl
Device Management
- Web Administrative Interface
- InControl Cloud Management
- Peplink AP Controller
- SNMP v1, v2c and v3
Package Contents
- AP One AX Lite
- Ceiling Mount Base (9/16” T-Rail)
- Ceiling Mount Base (15/16” T-Rail)
- Mounting Screw Set
Certifications
- FCC, CE, RoHS

Filter Reviews

Last 2 Weeks (0)

				81% (22)
				7% (2)
				4% (1)
				7% (2)
				0% (0)

		Show Brief Review
		Show 5Gstore Comments

Last 6 Months (0)

All Reviews (27)

Page 1 of 3 123

Only customers who bought this item from 5Gstore can write a review - these are all verified 5Gstore purchases

Date Added: 01/22/2024 by Myron O. (Winnebago, IL)

I love the management integration..... But it kind of ends there. Setup two of these in two different buildings. At first they seemed ok but then I started getting complaints about dropped Vonage calls on cell phones and later cell wifi calls. I bought a third one and created a mesh. Pretty much nothing changed. Started checking signals and these babies were weak. The old lynksys home router would blow them away. It's funny as the MAX BR1 in the RV has a great wifi signal. Not sure exactly where to go from here,
guess that is up to Pepwave..... but.... you will probably should steer clear of these Minis

Date Added: 08/10/2023 by Aaron. (Waukesha, WI)

Nice unit. Installed it towards the rear of my house for increased range.

Date Added: 05/26/2023 by Max L. (Bastrop, TX)

Very Rugged

Date Added: 05/26/2023 by Max L. (Bastrop, TX)

Very Rugged

Date Added: 08/02/2022 by Wiliam B. (Tempe, AZ)

Fantastic customer service!

Date Added: 04/25/2022 by Thomas D. (Dresden, OH)

Works well

Date Added: 12/17/2021 by Brad. (Pennant, SK)

Swapped out a AP One Enterprise, laptop in the next room went from 200-250Mbit to 500-550Mbit, as long as you keep your expectations reasonable, you should be pleased with it

Date Added: 06/18/2021 by Christopher H. (Wayne, ME)

I really wanted to love this access point. Bottom line is that 5GHz performance is 1/3 of the AC Mini and the power consumption and heat generation is quite high, hot to the touch! The day I received this, it got discontinued at the 5GStore. As a result of this, I am either getting the new "Lite" version or another AC Mini.

Date Added: 05/22/2021 by Doug B. (Deer Park, WA)

Haven't set it up yet.

Date Added: 05/17/2021 by Chad D. (Kansas City, MO)

Great AP so far!

Page 1 of 3 123

If you purchased this item, Login to write a review.

Q & A

Got questions about this product? Here you can view questions that other customers have asked (and the answers!). If you have a question that hasn't been answered below, you may submit a new question and 5Gstore will answer it!

Click here to submit a new question

Sort By:

Do the AP One devices require InControl fro management, or can they be managed via a web browser?

The AP devices have their own web admin you can access for management.

What power supply works with the Pepwave AP One AX Lite?

5Gstore item number 7922 (model ACW-602-US) works with the AP One AX Lite to provide AC power.

Does the Peplink AP One AX Lite come with a power supply?

No, it doesn't. If your router/switch does not support PoE output, you can use a PoE injector to add power or a standard 12V3A power supply would work.
