Built for vehicle and IoT deployments

The R2100 Series is a high-bandwidth, exterior-mounted solution that provides mass transit, public safety, and other organizations with the latest in 5G performance. Integrating the modem, antennas, and router into a single aerodynamic, ruggedized casing, this simplified form factor reduces installation complexity and cost.

BENEFITS

  • Deploy the integrated 5G NR / Cat 20 LTE modem, antenna, and Wi-Fi 6-equipped router in one complete package
  • Install as a self-contained 5G router or supplement an existing router as a 5G adapter
  • Provide easy installation with a power cable or Power over Ethernet (PoE) and no coax cables
  • Define policies through centralized cloud-based management for easy deployment at scale
  • Prioritize access on public safety networks for reliable, secure connectivity
  • Create a cellular coverage map of your area’s 5G and LTE coverage
  • Integrate into Automatic Vehicle Location systems with GNSS/GPS

Hardware Specs

Category

Mobile & IoT
Cloud Management

Yes
Wireless Connectivity

Dual Connectivity; 5G & Cat 20 LTE
5G Status

5G embedded
Form Factor

Polycarbonate
Ethernet Ports

1 x 2.5 GbE RJ45
Network Operator Standards

PTCRB (U.S. & Canada), GCF (worldwide)
Network Operator Certifications

AT&T, T-Mobile, Verizon
Regions

North America, Latin America, Europe, Africa/Middle East, Asia-Pacific
Public Safety Networks

FirstNet Trusted, T-Mobile Connecting Heroes, Verizon Frontline
Throughput

900 Mbps (Firewall)
VPN Tunnel Count

10
Wi-Fi

Dual-band, dual-concurrent; 802.11ax (Wi-Fi 6)
GNSS/GPS

Passive
PoE

802.3at
Operating Temperature

-30 °C to 70 °C (-22 °F to 158 °F)
Rack Mountable

No
Private Cellular Network

Yes — CBRS, 4G LTE, 5G
R2100 Series 5G Ruggedized Router Quick Start Guide(14535).pdf
r2100-series5g-ruggedizedrouter-2024-02-19(14535).pdf



Specifications:

No. of Cellular Connectors 0
No. of WiFi Connectors 0
No. of GPS Connectors 0
No. of LAN Ports 1
No. of WAN Ports 0
No. of Fiber (SFP) Ports 0
No. of Serial Ports 0
No. of Embedded Modems 1
Ports Configurable as LAN/WAN No
WAN Throughput Speed 900 Mbps
SIM Card Size 4FF
Length (in) 4.5
Width (in) 15.7
Height (in) 3.2
Weight (lb) 3
Minimum Temperature (F) -22
Maximum Temperature (F) 158
Material Polycarbonate
Antennas Included No
Modem Expansion Slot No
Modem Replaceable No
FIPS Certified Yes
WiFi Support WiFi 6
Cloud Management Included Yes
Power Input DC input steady state voltage range: 9–36 VDC & 802.3at PD Type 2, Class 4 (30 W) PoE
Bluetooth No
Bonding Support No
IP Passthrough Yes
