Peplink Antenna Max Duo Enclosure - ANT-MAX-DUO
  • Peplink Antenna Max Duo Enclosure - Open view with BR2 Pro 5G
  • Peplink Antenna Max Duo Enclosure - Open, front side view with BR2 Pro 5G

Peplink Antenna Max Duo Enclosure

31 Support Docs
Not yet Shipping
Item Number: 20773
Model: ANT-MAX-DUO

Price:

$799.00

Peplink offers an optional metal L-mount kit that is compatible with this product. It is recommended for high-wind conditions, as it provides enhanced durability and stability.
Optional Mounting Hardware: - details
Similar Products Compare All...

Contact Me When the Peplink Antenna Max Duo is Available!

The Peplink Antenna Max Duo is a new product and is not yet available. It is expected around July/August of 2025. Sign up here to be notified when it's available, or contact us today to discuss alternative in stock options!
Email Address: *
Name: *
Phone:
Quantity Needed
Comments:



Peplink Antenna Max Duo is an IP67 enclosure. It comes with right-angle connectors for 4G/5G, WiFi and GPS.

Support for multiple router combinations, such as:

  • BR2 Pro 5G
  • BR1 Pro 5G + BR1 Pro 5G + PoE Splitter
  • BR1 Pro 5G + BR1 Mini 5G + PoE Splitter

Specifications

  • Connections:
    • 8x 4G/5G with SMA/Male
    • 2x WiFi with RP-SMA/Male
    • 1x GPS with SMA/Male
  • Enclosure Material: UV Stable PC
  • Mounting Options: Surface, wall, pole, deck
  • Compliance: ROHS, REACH, WEEE
  • Enclosure Flammability: UL 94 V-0 (1.47 mm)
  • UV resistance: UL 746C (F1 long-term UV exposure)
  • Salt Spray: MIL-STD 810F/ASTM 8117
  • Operating Temperature: -40° - 176°F / -40° - 80°C
  • Storage Temperature: -40° - 176°F / -40° - 80°C
  • Product Dimensions:
  • Package Contents:
    • Antenna Box
    • L-Mount Set
    • Double sided 3M adhesive pad
    • 3pcs Cable Gland
    • 2pcs Hole Plug

Latest Blog Posts About This Product


Latest YouTube Videos About This Product




Specifications:

Country of Origin Taiwan
No. of Cellular Connectors 8
No. of WiFi Connectors 2
No. of GPS Connectors 1
Cellular Connector SMA Male
WiFi Connector RP-SMA Male
GPS Connector SMA Male
Antenna Type Outdoor
Antenna Style Omni
Antenna Mount Panel/Enclosure
Antenna Color White
Length (in) 16.83
Width (in) 16.83
Height (in) 4.82
Maximum Gain 8.1
Impedance Ω (Input/Output) 50
Cable Length (in) pigtails
Minimum Temperature (F) -40
Maximum Temperature (F) 176
Material UV stable PC
VSWR (Voltage Standing Wave Radio) < 2.5 over 95% of the band (cell); <2.0 (GPS), <2.5 (WiFi)
Noise Figure 2.5dB
