This 75' ultra low loss cable has an SMA/Male connector on one side and an SMA/Female connector on the other side. It is typically used to connect an antenna with an SMA/Male connector to a router or amplifier with an SMA/Female connector.

Specifications:

Cable length: 75'
Connectors: SMA/Male & SMA/Female
Cable diameter: 10.2mm (0.4in)
Impedence: 50ohms

Signal Loss:

The amount of signal attenuation you'll see depends on which frequency you're using. This cable averages approximately 3.8dB of signal loss. Attenuation for each frequency is below:
- 700mhz: 2.6dB
- 800mhz: 2.8dB
- 1700mhz: 4.1dB
- 1900mhz: 4.4dB
- 2100mhz: 4.6dB
- 2400mhz: 5.0dB
- 2500mhz: 5.1dB
Approximately .5dbm is lost at each connection between 2 cables
To prevent excessive signal loss, this cable should NOT be daisy chained with other cables! It is always better to use one longer piece of cable than to screw two shorter cables together.
