This is a special-order item that requires additional lead time. Contact us before ordering if you need a more exact ETA.
MobileMark antennas are trusted in commercial fleet operations worldwide. The MobileMark LTMG502 5-in-1 Antenna improves network signals when traveling and can be installed through the roof to widen your frequency range. This black GPS plus 2x cellular and 2x Wi-Fi antenna is a low-profile solution to your fleet. This versatile MobileMark antenna contains five different elements for use with modern LTE multiple input, multiple output (MiMo) modems, GPS and dual-band Wi-Fi.
MobileMark antennas offer field-tested designs that meet industrial and military standards for shock, vibration and UV-resistance. In addition, this unit has a high temperature operation range (-40° to 176° Fahrenheit). The LTMG502 antenna comes with five 15’ long cables that can be bundled and stored when not in use. In addition, this MobileMark LTMG502 antenna requires a metal ground plane and is attached to a vehicle by drilling a small hole in the roof. For more information about this MobileMark LTMG501 5-in-1 Antenna, contact our support team! We’re here to help you find the right MobileMark antenna for your business’ mobile networking needs.
This antenna requires that you drill a hole in the top of your car/RV/bus to install it, and a minimum 8x8" metal ground plane is recommended. If your vehicle's roof is fiberglass or another material, copper or aluminum tape in an X shape can be substituted as a ground plane. A ground plane is not required but will improve performance.
Features:
- Low profile
- Through-roof screw-mount (similar to NMO style)
- 5-cables, multi-band antenna for LTE MIMO, WiFi and GPS/GLONASS
- Single mounting hole; easier installation
- Field proven design; dependable link
- Mechanically sound, meets Industrial & Military specs
*This antenna has five cables - two to connect to your device's cellular connectors, one to connect to a GPS connector, and two to connect to WiFi connectors. It can be used JUST for celllular use if you like the style of this antenna but have no use for GPS or WiFi (or vice versa) - you can simply leave the unused cables bundled up out of the way.
Specifications:
- Frequency and gain:
- Cable 1 & 2 (cellular):
- 3db at 694-960mhz
- 4db at 1710-3700mhz
- Cable 3 & 4 (WiFi):
- 5db at 2400-2500mhz
- 5db at 4900-6000 mhz
- Cable 5 (GPS/GNSS):
- 1561, 1575, & 1602 MHz, LNA 26 dB, 5 dBi
- VSWR: 2:1 VSWR over Range
- Impedance: 50 Ohms
- Cable: 5 x 15' RF195
- Connectors: 3 x SMA/Male (cellular and GPS) and 2 x RP-SMA/Male (WiFi)
- Dimensions: 2.38" height, 5.5" diameter
- Radome material: ASA UV-Stable Plastic
- Operating temperature: -40 to +80° C
- Mounting:
- 7/8” (22mm) diameter feed through 3/4”(19mm) long thread for up to 1/2” (12mm) thick surface
- 8x8" metal ground plane recommended; copper or aluminum tape in an X shape can be used as a ground plane on non-metal surfaces if necessary.
- Shock & vibration: EEE1478, EN61373, MIL-810G, TIA 329.2-C
- Water Ingress: IP67
