MP70, 4G LTE-A Pro Router, Global, Wi-Fi, includes 1-year AirLink Complete The Sierra Wireless AirLink MP70 is a purpose-designed vehicle router made for demanding environments such as public safety, public transportation and commercial transit. It contains an embedded APAC modem. This mobile transit router allows you to connect laptops, smartphones and other devices to perform mission-critical tasks such as data transfer, record management and live video streaming in a vehicle. Vehicle location and fleet management with the AirLink MP70 mobile router are fast and reliable using GNSS satellite positioning technology or the Inertial Navigation System. Integrated Vehicle Telemetry will monitor both vehicle and driver performance to proactively identify potential problems with each. The router will stand up to tough working conditions thanks to its industrial grade construction that includes die-cast aluminum housing, thermal output management, water/dust resistance and transient surge protection. 5Gstore.com provides free technical support for a year to help you get your public safety vehicle router set up for reliable always-on performance. Router Features: Internet Connections Supported: 1 Embedded LTE IMPORTANT: you will need a 2mm Hex L-wrench (not included) to access the SIM slot on the router, WiFi as WAN* ( more info ) Networks Supported for Embedded Modem: 2100(B1), 1800(B3), 850(B5), 2600(B7), 900(B8), 850(B18), 850(B19), 1500(B21), 700(B28), TDD 38, TDD 39, TDD 40, TDD 41, 2100(B1), 850(B5), 800(B6), 900(B8), 1700(B9), 850(B19) TD-SCDMA: B39 WiFi Standard: 802.11 b/g/n/ac, dual-band 2.4GHz/5.0GHz WiFi Range: 150-200' Ports: 4 x 10/100/1000 LAN, 1 RS-232 serial Power supply: Hardwire DC power supply; AC power supply and cigarette lighter power supply are available separately Size: 7.5" x 1.75" in x 4.1" download the MP70 datasheet *Compatibility with all WiFi networks cannot be guaranteed. Networks requiring authentication on a "splash page" (e.g. Starbucks WiFi) in particular can be hit or miss. 1104074 1104074

Sierra Wireless

Router

812320005470

$ $1,099.00 812320005470 https://5gstore.com/product/9081_sierra_wireless_airlink_mp70_vehicle_router_with_apac_modem_wifi.html

The Sierra Wireless AirLink MP70 is a purpose-designed vehicle router made for demanding environments such as public safety, public transportation and commercial transit. It contains an embedded APAC modem. This mobile transit router allows you to connect laptops, smartphones and other devices to perform mission-critical tasks such as data transfer, record management and live video streaming in a vehicle.

Vehicle location and fleet management with the AirLink MP70 mobile router are fast and reliable using GNSS satellite positioning technology or the Inertial Navigation System. Integrated Vehicle Telemetry will monitor both vehicle and driver performance to proactively identify potential problems with each. The router will stand up to tough working conditions thanks to its industrial grade construction that includes die-cast aluminum housing, thermal output management, water/dust resistance and transient surge protection. 5Gstore.com provides free technical support for a year to help you get your public safety vehicle router set up for reliable always-on performance.

Router Features:

Internet Connections Supported: 1 Embedded LTE IMPORTANT: you will need a 2mm Hex L-wrench (not included) to access the SIM slot on the router, WiFi as WAN* (more info)
Networks Supported for Embedded Modem: 2100(B1), 1800(B3), 850(B5), 2600(B7), 900(B8), 850(B18), 850(B19), 1500(B21), 700(B28), TDD 38, TDD 39, TDD 40, TDD 41, 2100(B1), 850(B5), 800(B6), 900(B8), 1700(B9), 850(B19)
TD-SCDMA: B39
WiFi Standard: 802.11 b/g/n/ac, dual-band 2.4GHz/5.0GHz
WiFi Range: 150-200'
Ports: 4 x 10/100/1000 LAN, 1 RS-232 serial
Power supply: Hardwire DC power supply; AC power supply and cigarette lighter power supply are available separately
Size: 7.5" x 1.75" in x 4.1"
download the MP70 datasheet

*Compatibility with all WiFi networks cannot be guaranteed. Networks requiring authentication on a "splash page" (e.g. Starbucks WiFi) in particular can be hit or miss.

Latest Blog Posts About This Product

How to Register for Sierra Wireless AirLink Management Service (ALMS)

Latest YouTube Videos About This Product

AirLink MP70 _ LTE-Advanced Vehicle Router (1104074).pdf

Specifications:

Country of Origin	China
No. of Cellular Connectors	2
No. of WiFi Connectors	3
No. of GPS Connectors	1
Cellular Connector	SMA Female
WiFi Connector	RP-SMA Female
GPS Connector	SMA Female
No. of LAN Ports	4
No. of WAN Ports	0
No. of Fiber (SFP) Ports	0
No. of Serial Ports	1
No. of Embedded Modems	1
Ports Configurable as LAN/WAN	Yes
USB Port	LAN
WAN Throughput Speed	1 Gbps
SIM Card Size	2FF
Length (in)	4.4
Width (in)	7.5
Height (in)	1.75
Weight (lb)	1.68
Minimum Temperature (F)	-22
Maximum Temperature (F)	158
Antennas Included	No
Modem Expansion Slot	No
Modem Replaceable	No
FIPS Certified	No
WiFi Support	WiFi 5
Cloud Management Included	Yes
Power Input	7 to 36 VDC
Bluetooth	No
Bonding Support	No
IP Passthrough	Yes
