Sierra Wireless AirLink XR80 Vehicle Router with 5G/Cat 20 LTE Modem (No WiFi)

In Stock

Item Number: 10927
Model: 1104793
Have a large deployment?
Request a Quote



AirLink Complete is a subscription service that combines best-in-class network management software, industry-leading technical support and warranty. It is a cost-effective way to ensure your mission critical infrastructure operates at peak efficiency.
Upgrade AirLink Complete (XR80, new device) - details

The supercharged AirLink XR80 is optimized for fixed and mobile applications. The available dual-5G cellular radio and 5X4 MIMO Wi-Fi 6 delivers flexibility for customized configurations. The AirLink XR80 supports complete device-to-cloud security, reduces your total cost of ownership with ALMS Out-of-Band management, and with the cartridged-based design, enables long-term expandability and upgradability.

The AirLink XR80 is a fully-supported, out-of-the box solution complete with integrated device management and 24/7 technical support. AirLink Connection Manager delivers complete VPN security and our AirLink Professional Services maximizes your system performance and customer satisfaction.

Router Features:

  • Internet Connections Supported: 1 Embedded 5G/Cat 20 LTE IMPORTANT: you will need a 2mm Hex L-wrench (not included) to access the SIM slot on the router
  • Networks Supported for Embedded Modem:
    • 5G: Sub-6: n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40, n41, n48, n66, n71, n77, n78, n79
    • LTE: 2100(B1), 1900(B2), 1800(B3), AWS(B4), 850(B5), 2600(B7), 900(B8), 700(B12), 700(B13), 700(B14), 700(B17), 850(B18), 850(B19), 800(B20), 1900(B25), 850(B26), 700(B28), 700(B29), 2300(B30), 1500(B32), TDD B38, TDD B39, TDD B40, TDD B41, TDD B42, TDD B46, CBRS B48, 1700(B66), 600(B71)
  • WiFi Standard: N/A
  • Ports: 4 x 10/100/1000 LAN, 2 RS-232 serial
  • Power supply: Hardwire DC power supply; AC power supply is available separately
  • Size: 6.69" x 8.66" in x 2.08"


  • Designed for fixed and mobile mission and business-critical applications that require ultimate connectivity and reliability
  • Real-time connectivity with unmatched uplink and downlink speeds using 5G, Wi-Fi 6 and 5Gbps Ethernet technology
  • "Always-on" connectivity delivers consistent primary and backup connectivity for public and private networks using AirLink Cognitive Wireless
  • Simplified set up and useability with new AirLink OS and upgraded AirLink Management Service (ALMS)
  • New AirLink Premium with ALMS Out-of-Band Management provides zero-touch set up and reduced service calls
  • Ready for your Edge computing workloads
  • AirLink Complete: Best-in-class support services covering AirLink XR80 devices. Includes:
    • AirLink Management Service (ALMS) network management and optional ALMS Advanced Mobility Reporting (AMR)
    • 24/7/365 Tier 1 technical support from wireless experts via phone or online access
    • Extended hardware warranty – up to 5 years
  • VPN: AirLink Connection Manager (ACM) is a mobile-optimized VPN solution that securely extends the enterprise network to the vehicle.
  • Professional Services: Full product life-cycle services including solution consulting and solution implementation services delivered by Sierra Wireless Network Engineers and Program Managers.


  • Cellular WAN
    • Peak DL: 5G - Up to 4.14 Gbps DL, 4G LTE-A Pro CAT20 - Up to 2 Gbps DL
    • Peak UL: 5G - Up to 660 Mbps UL, 4G LTE-A Pro CAT20 - 210 Mbps UL
    • 5G Frequency Bands: Sub-6: n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40, n41, n48, n66, n71, n77, n78, n79
    • 4G LTE Frequency Bands: 2100(B1), 1900(B2), 1800(B3), AWS(B4), 850(B5), 2600(B7), 900(B8), 700(B12), 700(B13), 700(B14), 700(B17), 850(B18), 850(B19), 800(B20), 1900(B25), 850(B26), 700(B28), 700(B29), 2300(B30), 1500(B32), TDD B38, TDD B39, TDD B40, TDD B41, TDD B42, TDD B46, CBRS B48, 1700(B66), 600(B71)
    • 3G WCDMA/HSPA+ Frequency Bands: 2100(B1), 1900(B2), 1800(B3), AWS(B4), 850(B5), 800(B6), 900(B8), 1700(B9), 850(B19)
    • LPWA Frequency Bands: B1, B2, B3, B4, B5, B8, B9, B10, B12, B13, B14, B17, B18, B19, B20, B25, B26, B27, B28, B66
    • Approvals:
      • Regulatory: FCC, IC, PTCRB, GCF, CE, RED, RCM
      • Carrier: Verizon, AT&T, T-Mobile (pending)
  • Host Interfaces
    • 3x RJ-45 Ethernet ports (1x5Gbps with PTP IEEE 1588, 2x1Gbps)
    • LPWA ALMS Out-of-Band Management
    • USB 3.2 Type-C port
    • Dual RS-232 serial port on RJ-45
    • Aux Port (GPIO/CAN)
    • Dual SIM Slots
    • 7 FAKRA antenna connectors (Dual 4x4 Cellular, GNSS, LPWA)
  • Network and Routing
    • Sierra Cognitive Wireless
    • IPv4 and IPv6 Routing
    • Network Address Translation (NAT)
    • LAN Segmentation
    • IPv4 Passthrough and IPv6 Prefix Extension WAN/LAN Connection Policy Management Policy-Based Routing
    • QoS: Application/ Traffic Priority Queuing WAN Monitors: Connection Failure Recovery Configurable MTU size
    • Multiple LAN Support
    • Customize transmission buffer size
    • Static Routing
    • WAN Ethernet
  • VPN
    • Integrated with ACM VPN Server
    • IPsec protocol with IKEv1/IKEv2
    • FIPS 140-2
    • Encryption: AES128/AES192/AES256
    • Hashing: SHA256/SHA384/SHA512
    • Key Exchange: DHGroup14/15/16/17/18/19/20/21 LAN to LAN and Host to LAN
    • Up to 10 concurrent tunnels per link MOBIKE protocol
    • IP compression
    • Full/Split Tunnel
    • Dead Peer Detection (DPD)
  • Security
    • AAA: 802.1x /Radius authentication with Wi-Fi and Ethernet
    • Firewall: Stateful firewall with port forwarding, DMZ,
      WLAN Encryption: WPA2/WPA3 Personal/Enterprise
    • FIPS 140-2
  • Environmental
    • Operating Temperature: -30°C to +70°C / -22°F to +158°F
    • Storage Temperature: -40°C to +85°C / -40°F to +185°F
    • Humidity: 95% RH @ 60C
    • Military Spec MIL-STD-810G conformance to shock, vibration, thermal shock, and humidity
    • IP64 rated ingress protection
  • Power
    • Input/Operating Voltage: 7 to 36 VDC
    • Power modes: Peak 54W (4.5A @12V); Standby 55mW (4.5mA@12V)
    • Built-in protection against voltage transients including 5 VDC engine cranking
    • Ignition Sense with time delay shutdown
  • Dimensions
    • Size: 220mm x 170mm x 53mm (6.69in x 8.66in x 2.08in)
    • Weight 2.06 Kg (4.5 Lbs.)
  • Industry Certifications
    • Safety: IECEE Certification Bodies Scheme (CB Scheme), UL 60950
    • Vehicle Usage: E-Mark (72/245/EEC, 2009/19/EC), ISO7637- 2, SAE J1455 (Shock & Vibration)
    • Environmental: RoHS2, REACH, WEEE Rail Usage: EN50155 (Rolling Stock)
  • Support and Warranty
    • 3 year standard warranty
    • Optional additional 2 year warranty extension
    • Unrestricted device software upgrades
