This Device Requires a Dual Sim(Mini-2FF)
The AirLink RX55 is optimized for Industrial IoT with ultra-low power consumption and a rugged design for extreme conditions. With advanced networking and industry-standard container support capabilities, the RX55 delivers intelligence securely at the edge for mission-critical applications on both public and private networks. Its wide operating voltage makes it ideal for solar or battery-powered remote monitoring installations. Its compact, rugged design is built to withstand harsh conditions and, with edge intelligence capabilities, the router’s future-proof design enables applications including grid modernization, smart city, automation, and remote machine and sensor monitoring.
The AirLink RX55’s design along with its’ ultra-low power, ethernet, and dual-serial port makes it ideal for use in both fixed and mobile industrial applications including power and water utilities, oil fields, pipelines, mines, agriculture, manufacturing, waste management, private networking, and SCADA applications.
The RX55 solution delivers multi-band, worldwide support providing extensive public network coverage and best-in-class private networking coverage. The router supports FirstNet, Band 71, as well as most private networking bands including CBRS Band 48 in the U.S. The RX55 provides Cat 7 speed (300 Mbps downlink and 150 Mbps uplink) for data-intensive networks. Optional dual-band 2.4 and 5.0 GHz WiFi functions as an access point or hotspot. The RX55 also features a Gigabit Ethernet port, GPS for location tracking, and a serial interface. With its flexible WAN routing capabilities, AirLink OS enables industrial customers to create multiple concurrent data sessions through a new multi-APN solution.
Ideal Applications:
- Utilities
- Oil & Gas
- Public Safety
- Agriculture
- Environmental monitoring
- Critical Infrastructure
- Smart Cities
Key Features:
- 4G LTE-A
- 1 Gigabit Ethernet
- Dual RS-232 serial port (DB9) (with optional Y-cable)
- GNSS
- IP64 Rated
- Military Spec: MIL-STD-810G conformance to shock, vibration, thermal shock, and humidity
- AirLinkOS with AirLink Complete
- Maximize your AirLink RX55 hardware investment and ensure your applications operate at peak efficiency by subscribing to our best-in-class service and support including:
- AirLink Management Service (ALMS) network management
- Optional Advanced Mobility Reporting (AMR) Ÿ
- 24/7 Tier 1 technical support from wireless experts via phone or online access
- Extended hardware warranty – up to 5 years
- Networks Supported for Embedded Modem:
- 4G LTE: B2, B4, B5, B7, B12, B13, B14, B25, B26, B41, B42, B43, B48, B66, B71
- 3G HSPA+: B2, B4, B5
- Carrier Certifications:
- Pending Carrier Certifications:
Key Benefits:
- The compact size makes installation easier
- Out-of-the-box connectivity delivers same-day operations
- Connect to a wide variety of devices from video to low-power IoT
- Leverage the world of IoT to drive new business opportunities
- Ultra-low power, compact solution ideal for industrial environments
- Remote Management and end-to-end security to protect critical infrastructure
- Multi-Band Support (B71, CBRS) providing extensive coverage and best-in-class Private Networking Support
- Advanced networking capabilities with flexible software-defined routing functions
- Ruggedized to withstand extreme conditions
Specifications:
- Cellular WAN
- LTE Category: Cat 7
- Peak Download: Up to 300 Mbps DL
- Peak Upload: Up to 150 Mbps UL
- Supported Frequency Bands
- 4G LTE: B2, B4, B5, B7, B12, B13, B14, B25, B26, B41, B42, B43, B48, B66, B71
- 3G HSPA+: B2, B4, B5
- Approvals:
- Safety: IECEE Certification Bodies Scheme (CB Scheme)
- Vehicle Usage: E-Mark (UN ECE Regulation 10.04), ISO7637-2, SAE J1455 (Shock, Vibration, Electrical)
- Environmental Directives: RoHS2, REACH, WEEE, Prop 65
- Hazardous Environments: Class 1 Div 2 – Ambient temperatures of -30°C to +60°C
IECEx & ATEX
- Rail Usage: EN50155 (Pending)
- Regulatory: FCC, IC, PTCRB
- Carrier: Verizon, AT&T, T-mobile
- Pending: Bell, Telus, Rogers
- Public safety: First Net
- Host Interfaces
- 1x Gigabit Ethernet Port (RJ45)
- Dual RS-232 serial port (DB9) (with optional Y-cable)
- USB 2.0 Micro-B Connector
- 3 SMA antenna connectors (Primary, Secondary/Diversity, GPS)
- Active GPS antenna support
- Power
- Input
- Configurable I/O pin on the power connector
- Digital Input ON Voltage: 7 to 36 VDC
- Consumption
- LTE Idle Power: 900mW (75 mA @ 12VDC)
- Standby Mode Power: 53 mW (4.4 mA @ 12 VDC)
- triggered on low voltage, I/O or periodic timer
- Power Modes
- Low voltage disconnect to prevent battery drain
- Built-in protection against voltage transients including 5 VDC engine cranking and +200 VDC load dump
- Ignition Sense with time delay shutdown
- Configurable features and ports to optimize power consumption
- Serial
- Single RS-232 serial port (DB9)
- Network and Routing
- Sierra Cognitive Wireless
- IPv4 and IPv6 Routing
- Network Address Translation (NAT)
- Port Forwarding
- DHCP Server
- IP Passthrough
- LAN Segmentation
- IPv4 Passthrough and IPv6 Prefix Extension
- WAN/LAN Connection Policy Management
- Policy-Based Routing
- Configurable MTU size
- Static Routing
- WAN Ethernet
- Satellite Navigation (GNSS)
- 30-Channel GPS and GLONASS Receiver
- Security
- AAA
- 802.1x /Radius authentication with Wi-Fi and Ethernet
- Firewall
- Stateful firewall with port forwarding, DMZ
- WLAN Encryption
- WPA2/WPA3 Personal/Enterprise
- Firmware Update
- Events Engine
- Custom event triggers and reports
- Configurable interface, no programming
- Event Types: Digital Input, Network Parameters, Data Usage, Timer, Power, Device Temperature and Voltage
- Report Types: RAP, SMS, Email, SNMP Trap, TCP (Binary, XML, CSV)
- Event Actions: Drive Relay Output
- VPN
- Integrated with ACM VPN Server
- IPsec protocol with IKEv1/IKEv2
- FIPS 140-2 Level 1 compliant
- Encryption
- Hashing
- Key Exchange
- DHGroup14/15/16/17/18/19/20/21
- LAN to LAN and Host to LAN
- Up to 10 concurrent tunnels per link
- MOBIKE protocol
- IP compression
- Full/Split Tunnel
- Dead Peer Detection (DPD)
- Dimensions
- 119 mm x 33 mm x 85 mm (102 mm including wi-fi connectors)
- 4.69 in x 1.34 in x 3.35 in (3.70 in including connectors)
- 320g / 0.7lb
- Environmental
- Operating Temperature: -30°C to +70°C / -22°F to +158°F
- Storage Temperature: -40°C to +85°C / -40°F to +185°F
- Humidity: 95% RH @ 60°C
- Military Specification: MIL-STD-810G (Shock, Vibration, Thermal Shock, Humidity)
- IP64-rated ingress protection
- Airlink Services/Warranty
- Includes 1st Year AirLink Complete:
- AirLink Management Service (ALMS)
- Direct 24/7 Technical Support
- 1-year standard warranty; optional up to 5-year warranty extension
What's Included:
- RX55 Router
- DC Power Cable (Item #: 2000522)
- Quick Start Guide
